5MP ColorHunter HD Fixed Mini Bullet Analog Camera, TVI/AHD/CVI/CVBS support, IP67, 24/7 color images with white light illumination.

Model No :UAC-T125-AF28M-W

Category:

Have a question about this product? Ask Our Expert

  • NDAA

    Compliant

  • Protected By Our

    3 years warranty

Compatible accessories for this product

Description

  • 5MP high quality imaging
  • TVI/AHD/CVI/CVBS
  • Supports white light illumination, 24/7 color images
  • Supports 180° horizontal flip, 180° vertical flip
  • OSD configuration menu, easy to operate
  • IP67 waterproof and dustproof design, high reliability
  • OSD configuration menu in 11 languages
  • Built-in microphone for high quality audio transmission via coaxial cables
  • Metal front face and housing
  • 3-Axis

Additional information

Series

Essential

Megapixel

5MP

Product Type

Turret

Lens Length

Fixed

Compliance

IP67, NDAA

Specifications

Model UAC-T125-AF28M-W UAC-T125-AF40M-W
Sensor
Pixel 5MP
Size 1/2.7″
Minimum illumination 0.005lux (F1.4, AGC ON)
0 lux (white light on)
Lens
Lens 2.8mm 4.0mm
Lens mount M12
Angle of view H: 111.5°  V: 58.9°  D: 134.8° H: 89.6°  V: 48.3°  D: 106.4°
Illuminator
Illuminator Two white-light illuminators
Illumination distance 40m
Lifetime ≥60,000 hours
Video
Resolution 5MP@25fps: 2880(H)×1620(V); 5MP@20fps: 2592(H)×1944(V); 5MP@12.5fps: 2592(H)×1944(V)
4MP: 2560(H)×1440(V)
1080P: 1920(H)×1080(V)
Frame rate TVI: 5MP@20fps (default), 5MP@12.5fps, 4MP@30fps, 4MP@25fps, 1080P@30fps, 1080P@25fps
AHD: 5MP@20fps, 4MP@30fps, 4MP@25fps, 1080P@30fps, 1080P@25fps
CVI: 5MP@25fps, 4MP@30fps, 4MP@25fps, 1080P@30fps, 1080P@25fps
CVBS: PAL, NTSC
Shutter time PAL: 1/25s-1/50000s
NTSC: 1/30s–1/50000s
Exposure mode Four modes: Global (default), BLC, HLC, DWDR
Day/Night 24/7 color images
Digital noise reduction 2D
White balance Two modes: Auto (default), Manual
WDR DWDR
Flip Supports 180° horizontal flip, 180° vertical flip
Audio
Microphone Built-in Mic
Camera audio TVI: 5MP@20fps, 5MP@12.5fps, 4MP@30fps, 4MP@25fps, 1080P@30fps, 1080P@25fps
CVI: 5MP@25fps, 4MP@30fps, 4MP@25fps
Interface
Power 5.5mm power interface
Video output BNC, supports TVI/AHD/CVI/CVBS
Operating environment
Temperature -30°C to 60°C (-22°F to 140°F)
Humidity ≤95% (RH, non-condensing)
Surge protection 4kV
Ingress protection IP67
General
Power DC12V (±25%), with reverse polarity protection. Max 3.28W
Mount Surface mount (default), optional junction box and wall mount bracket
Dimensions Φ111mm*96mm (diameter*height)
Material Metal and plastic
Weight 356g (0.79lb)
Certification CB, CE, FCC, UL
