PW2020-22T2G-IN

$0.00

AI POE Switch

Category:

Have a question about this product? Ask Our Expert

  • NDAA

    Compliant

  • Protected By Our

    3 years warranty

Description

  • Using CAT.5 network patch cords support power for the wireless AP/CPE and IP camera/PTZ
  • Networking standard: IEEE802.3af/at/bt
  • POE power light blinks to determine the power status of the receiving end, and each blink is 2.7 watts.
  • PoE Watchdog AI Function: Detection front-end PoE cameras and PD, Automatic detection, Automatic restart
  • Upload port automatic flip (Auto MDI / MDIX)
  • 6KV lightning protection,8KV surge protection, anti-reverse connection, over-current protection, over-voltage protection, over-temperature protection, Short circuit protection
  • The Max output power of the port is 60W, which is convenient for hi-power equipment
  • Zero configuration feature power supply is automatically supplied to the adaptive equipment

Specification

Model PW2020-22T2G-IN
Ports 22X10/100/100Mbps PoE ports (RJ45)

2X10/100/1000Mbps PoE ports (RJ45)

2X10/1000Mbps uplink port (RJ45)
Transmission Rate 2000Mbps Full Duplex; 10 or 100 or 1000Mbps Half Duplex
Transmission Distance 0-100m
Performance

Specification

 Bandwidth: 12.4Gbps
Network Latency (10 to 1000Mbps): ≦16μs (use the 64byte package size)
MAC address table: 8K
The Frame Filter & Transmission Rate: 14800pps the most for 10M port, 148800pps the most for 100M port,1488000pps the most for 1000M port
Networking

Standard

 IEEE 802.3i 10BASE-T
IEEE 802.3u 100BASE-TX/ IEEE 802.3ab 1000BASE-T
IEEE 802.3xFlowControl
IEEE 802.3af/at/bt Power over Ethernet
Power Support Power input:  AC 110~220V Total≤300W

PoE Watchdog: Port 1~24

Power output: PoE1~22Port:1/2(+52V),3/6(GND)≤30W

PoE 23~24 Port:1245(+53V),3678(GND) compatible1/2(+52V),3/6(GND)≤60W
Protection Level Lightning Protection:6KV, Per: IEC61000-4-5

ESD Protection:8KV, Per: IEC61000-4-2
Physical Specifications Size(L*W*H): 430mm*180mm*45mm
Working

Environment

 Operating Temperature: -10℃ ~55℃ ( -14°~131℉)
Storage Temperature: -40℃ ~70℃ ( -104°~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Electromagnetic Compatibility CE mark
FCCPart15，Class B
VCCI ClassBEN55022 (CISPR 22)
C-Tick
Warranty Whole machine: 1 year
Package Content Installation Manual
