8MP Starlight, Laser, HLC, EIS, 120dB WDR, IP66, 33X optical zoom

Model No :IPC6658SR-X25-VF

$0.00

Category:
-40°C Temp Resist
AI

Have a question about this product? Ask Our Expert

  • NDAA

    Compliant

  • Protected By Our

    3 years warranty

Compatible accessories for this product

Description

• High quality image with 8MP,1/1.8’’ CMOS sensor
• 3840*2160@30fps in the main stream
• Ultra 265, H.265, H.264, MJPEG
• Triple streams
• 25X Optical Zoom
• Lighthunter technology ensures ultra-high image quality in low illumination environment
• Smart IR, up to 200m (656 ft) IR distance
• AC 24V±25%, DC 24V±25% or PoE power supply
• Alarm 2 in and 1 out, Audio 1 in and 1 out
• IP66 ingress protection

Additional information

Series

Professional

Megapixel

8MP

Compliance

IP66, NDAA

Features

-40°C Temp Resist, AI

Specifications

IPC6658SR-X25-VF
Camera
Sensor 1/1.8″, 8.0 megapixel, progressive scan, CMOS
Min. Illumination Colour: 0.003 Lux (F1.5, AGC ON)
0 Lux with IR
Day/Night IR-cut filter with auto switch (ICR)
Shutter Auto/Manual, 1 ~ 1/100000s
WDR Digital wide dynamic
S/N >56dB
Lens
Lens 6.0 ~ 150.0mm, AF automatic focusing and motorized zoom lens
Digital Zoom 16
Optical Zoom 25
Iris Auto; F1.5 ~ F3.4
Angle of View (H) 60.5° ~ 3.1°
Angle of View (V) 36.3° ~ 1.8°
Angle of View (O) 71.4° ~ 3.7°
DORI
DORI Distance Lens (mm) Detect (m) Observe (m) Recognize (m) Identify (m)
6.0 143.1(469.5ft) 57.2(187.8ft) 28.6(93.9ft) 14.3(46.9ft)
150.0 3116.3 (10223.9ft) 1246.5(4089.6ft) 623.3(2044.8ft) 311.6(1022.4ft)
Illuminator
Vari-focal Laser Up to 200m(656ft)
Wavelength 850nm
IR On/Off Control Auto/Manual
Video
Video Compression Ultra 265, H.265, H.264, MJPEG
Frame Rate Main Stream: 8MP(3840*2160),Max 30fps(Max 20fps when AI functions enabled);
Sub Stream: 2MP (1920*1080), Max 30fps;
Third Stream: D1 (720*576), Max 30fps;
Video Bit Rate 128 Kbps~16 Mbps
H.264 Type Baseline Profile/Main Profile/High Profile
H.265 Type Main Profile
U-code Susepport
ROI Up to 8 areas
Video stream Triple streams
OSD Up to 8 OSDs
Privacy Mask 24 areas, up to 4 blacks in the same picture
White Balance Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Digital noise reduction 2D/3D DNR
Smart IR Support
Flip Normal/Flip Vertical/Flip Horizontal/180°
HLC Support
BLC Support
Defog Digital Defog
Events
Basic Detection Motion detection, Audio detection, Tampering Alarm;
Auto tracking Support later
General Function Watermark, IP Address Filtering, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication
Audio
Audio Compression G.711U,G.711A
Audio Bitrate 64 Kbps
Two-way Audio Support
Suppression Support
Sampling Rate 8KHZ
Storage
Edge Storage Micro SD, up to 256 GB
Network Storage ANR,NAS(NFS)
Network
Protocols IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP, SSL/TLS
Compatible Integration ONVIF (Profile S, Profile G, Profile T), API, SDK
User/Host Up to 32 users. 2 user levels: administrator and common user
Security Password protection, strong password, HTTPS encryption, Export operation logs, basic and digest authentication for RTSP, digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF
Client EZStation
EZLive
Ezview
Web Browser Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below
Pan & Tilt
Pan Range 360° (endless)
Pan Speed 0.1°/s ~ 200°/s
Preset speed: 300°/s
Tilt Range –15° ~ 90° (auto reverse)
Tilt Speed 0.1° ~ 200°/s
Preset speed: 240°/s
Number of Presets 1024
Patrol Preset patrol, route patrol, recorded patrol
Patrol Stay Time 15s~1800s
Preset Image Freeze Support
Home Position Support
Interface
Audio I/O 1/1
Alarm I/O 2/1
Serial Port 1 RS485
Built-in Mic N/A
Built-in Speaker N/A
WIFI N/A
Network 1 * RJ45 10M/100M Base-TX Ethernet
Video Output 1 BNC, impedance 75Ω; amplitude 1V [p-p]
Certification
EMC FCC CFR 47 Part 15
EN 55032:2015
EN 55024:2010
EN 61000-3-2:2014
EN 61000-3-3-2013
Safety IEC 62368-1
EN 62368-1
UL 60950-1
Environment CE-ROHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); REACH (Regulation (EC) No 1907/2006)
Protection Ingression protection: IP66 (IEC 60529-2013)
General
Power AC 24V±25%, DC 24V±25%, PoE (PSE Required)
Power consumption: Max 58W
Power Interface Wires with cold-pressed terminal
Dimensions (Ø x H) Ø227 x 384.8mm (Ø8.9” x 15.1”)
Weight 5.61kg(12.36lb)
Working Environment -40℃~65℃(-40°F ~ 149°F),≤95%RH
Storage Environment -40℃~70℃(-40°F ~ 158°F),≤95%RH
Surge protection 6KV
Vandal Resistant N/A
Ingress Protection IP66
Reset Button Support
